Top 10 Items Commonly Missing from Fenestration System Shop Drawings - Downloadable


Standard Price

$0.00

Member Price

$0.00

Items commonly missing from fenestration systems shop drawings


Standard Price

$0.00

Member Price

$0.00


Product Details

Shop drawings, for glass and aluminum windows, curtain walls and skylights, must document and detail all requirements of design parameters, material ordering, fabrication and erection. Failure to properly document these requirements can result in numerous errors and project delays. In order to provide a reminder of key elements of successful shop drawings, members of the GANA Building Envelope Contractors (BEC) Division developed this list of the Top Ten items commonly missing from fenestration systems shop drawings. This document was published in March 2014. All purchases will be electronically accessed or delivered.

Additional Product Photos
