Guidelines for Capillary Tubes (TB 1601-24) - Downloadable Out of Stock
Standard Price
$30.00
Member Price
$0.00
Capillary tubes have many benefits - this guide presents considerations for their use
Standard Price
$30.00
Member Price
$0.00
Size
Color
Product Details
While the benefits of using capillary tubes are straightforward, there are numerous issues when considering their use including:
- Magnitude of elevation change to require use
- IGU pressurization due to temperature difference
- Use with insulating gases
- IGU sizes and aspect ratios
- Glass thickness, type and coatings
- Glazing space thickness
- Short term (in transit) vs. long term (installed) elevation and/or temperature changes
- Types of edge seal construction
- Multiple-cavity IGUs (triples, quads, etc.)
- Proper IGU design and fabrication for use of capillary tubes
All purchases will be electronically accessed or delivered.
The Technical Services Division of the National Glass Association (NGA) and the Fenestration & Glazing Industry Alliance (FGIA) have produced this Glass Technical resource solely for informational purposes. This resource was developed by dedicated member volunteers and subject matter experts. The original version of this document was approved and published in 2014. This version of the document was updated and published in May 2024.
The NGA Board of Directors has voted to make this resource free to NGA members. Not a member? Join today.
